TYPICAL LAYOUT APPLICATIONS
DRAGON 1
DRAGON 2
Modem
DRAGON 3
HOST PC
F734-E
Stand Alone Mode - STAR MODEM™ Server Connected to Host PC
433 MHz/910MHz
RF Connection
DRAGON
5 Volt
Modem
2.4 GHz
Network
DL8700
Stand Alone Mode - STAR MODEM™ Server Connected to DL8700
71
