INSTALLATION
Mounting the stand
1. Place the TV with the front panel facing downwards.
Make sure to place the front panel on soft cloth, soft
pads or another soft piece of material.
2. Insert the stand into the holes located on the bottom of
the TV (L for left, R for right).
3. Insert the screws into the sockets and tighten them.
Mounting on the wall
The TV has VESA mounting holes for wall mounting bracket
(not included). Make sure that your bracket is the
compatible one with the TV. VESA standard determines the
width and height of the mounting holes for the bracket.
Before mounting the TV on the wall:
• Follow all instructions from the wall mount manufacturer.
• If you have any doubts about your ability to safely install
EN
the TV on the wall, contact a professional.
• Make sure that the wall can support the weight of the TV
and the mount.
• When installing the TV on the wall, do it with someone to
help you.
• Make sure that the TV has at least 20 cm clearance from
each side.
14
Owner's manual Owner's manual
BUTTONS ON THE TV
Note: the location, name and availability of the buttons may
vary according to the TV model.
• Press and hold the button to turn on the TV.
• Press the button to turn off the TV.
• SOURCE: opens the inputs menu.
• MENU: open the main menu.
• CH-: previous channel/option.
• CH+: next channel/option.
• VOL-: decrease volume.
• VOL+: increase volume.
• POWER: turn on or off the TV.
SOURCE MENU CH- CH+ VOL-
SOCKETS
On the side
1. HDMI ports
2. USB port
3. CI socket
4. Headphone jack output
DIGITAL
AUDIO OUT
(OPTICAL)
ETHERNET
1 2
VOL+
L R
AV IN AUDIO IN DVB-S (LNB IN) DVB-T2 /-C (Cable)
3
CI
4
15
