OPERATING INSTRUCTION
EN
I I N N S S T T R R U U C C T T I I O O N N M M A A N N U U A A L L
CONTACT GRILL + WAFLE MAKER GK2000W
CONTACT GRILL + WAFLE MAKER
• GENERAL DESCRIPTION
1. Control panel with display
2. Base
3. Grill plates
4. Waffle plates
5. Lid
6. Handle
7. Plate lock
8. Locking device "180 degrees"
9. Plate lock
10. Grease container
• INTENDED USE
The GK2000W grill is able to replace 2 appliances, often found in modern kitchens. This is possible thanks
to 2 types of interchangeable plates, with the help of which a traditional grill can be turned into a waffle maker.
This is an ideal solution to save a lot of space in the kitchen.
• SETTING UP THE APPLIANCE
− Make sure that the appliance, the plug and the power cord are in order and that all parts of the packaging
have been removed before you start using the appliance.
Important: The appliance may give off a smell while being used for the first time. The smell is
associated with the manufacturing procedure. It is a natural process which ceases to occur after a
certain period of time. Ensure a suitable ventilation in the room, e.g. by opening a window. Use the
toaster with any food products while using it for the first time.
- The appliance is equipped with 2 types of hotplates:
• grilling plates (3)
• waffle plates (4)
- To remove the plates, press the buttons (9) located next to the plates.
- To insert the plates, slide their bottom edges into the holes in the housing and press from the top.
• USE
− Place the device on a flat, stable and heat-resistant surface.
− Install the appropriate heating plates (3 or 4) and grease them.
− When using the grill plates (3) in the base (2), install the grease container (10).
Contact grill, waffle maker
− Close the lid (5).
− Turn on the appliance to the mains compatible with the parameters specified above, a single beep will sound,
all the lights on the control panel (1) will flash once, and the power switch light
will be in standby mode.
− Touch the power switch
− Press the appropriate icon to select the desired program, the "Preheat" light will illuminate, and the
corresponding time and temperature will be displayed on the screen.
− The temperature and time can be changed by pressing the time
the "-" and "+" symbols.
− When heating is complete, the buzzer will sound three times and the "OK" light will flash.
− Put the prepared food (grilling) or carefully pour the batter (waffle baking), close the lid and press the "OK"
button to start the selected program for frying or baking the product.
10
GK2000W
- the lights on the control panel (1) will illuminate.
• TECHNICAL DATA:
− power: 1800 W
−
supply voltage:
220-240V ~ 50/60Hz
will start flashing. The device
and temperature buttons , followed by
