CAMSET7 – B/W VIDEO INTERCOM SYSTEM
CAMSET8 – COLOUR VIDEO INTERCOM SYSTEM
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying this device! You have bought a closed-circuit television system consisting of an outdoor camera
and a central display unit to be mounted indoors. The device is equipped with duplex telephony. You no longer have
to answer the door to know who is ringing your doorbell! IR LEDs provide visibility in the dark and the device is easy
to install and operate. This device will also make your home safer. Read this manual before installing the device in
order to familiarise yourself with its operation.
2. Description
a) Camera (Outdoor Section)
1. camera
2. IR LEDs (only B/W camera for CAMSET7)
3. bell button
4. speaker
5. microphone
6. input for indoor section
7. tamper switch: activated when camera
is removed
b) Central Unit (Indoor Section)
1. power indication
2. monitoring key: image + sound
3. alarm button
4. key for door opener
5. contrast adjustment
6. volume adjustment
7. display
8. microphone
9. speaker
10. button for two-way communication when receiver is
picked up
11. connector for electric lock: connections 11 & 12
for CAMSET7, connections 3 & 4 for CAMSET8
12. input 18VDC
13. input for cable to camera
CAMSET7 & 8
Fig. 2
Fig. 2
1
Fig. 1
