3_DIAGRAM OF PRODUCT

1 2
1_ Indicator LED
2_ Charging contact
3_ Micro USB port

4_INSTRUCTIONS

Connect the USB port cable with the RG100 Desk
Charger on the rear side.
Connect the other end of the cable to the power supply
adapter. Insert the power supply adapter into a power
socket.
RG 100 DESK CHARGER MANUAL
3
RG 100 DESK CHARGER MANUAL

5_SAFETY GUIDE

Please use the RG100 Desk Charger in dry places /
environment.
Please connect the RG100 Desk Charger to right
output voltage (marked on product).
The cable should be placed in the proper position;
so that no one can step on, stumbling, flooding or
squeezing it.
This charger is specially designed for RG100.

6_TECHNICAL PARAMETERS

To charge the RG100, put it into the RG100 Desk Charger
The indicator LED of the RG100 Desk Charger is swit-
ching from green to red. Charging is also indicated on
the display of the mobile phone.
When the battery is nearly full, the indicator LED
is switching to yellow.
When the battery is fully charged, the indicator LED
of the RG100 Desk Charger is switching to green.
Max. output voltage 1000mA±100mA
Input voltage: DC 5±0.3V, Input max. currently:
1000mA±100mA
Charging saturation (25 °C): 100%
