7. Connection and Operation

a) Audio

First connect the product to the desired audio device (e.g. sound system, AV receiver,
etc.). You can choose between the analogue and digital outputs here.
Analogue connection:
• Connect the enclosed 3.5 mm jack plug cable to the socket "AUX" of the music box.
• Now connect the other end of the cable to your sound system, AV-receiver or any
other device with a 3.5 mm jack plug input.
Digital connection:
• For this, connect the enclosed Toslink cable to the digital audio output "OPTICAL" of
the music box.
• Connect the other end of the cable to the corresponding socket of your sound system,
AV-receiver or any other device that has an optical digital input (Toslink).
b) Voltage Supply
Please observe that the system will start up as soon as the music box is connected
to the voltage supply. Of course, you can connect or disconnect devices and cables
in operation.
• Connect the micro-USB plug of the enclosed USB cable to the USB socket "DC" at
the product.
• Connect the other end of the cable to a suitable voltage source (5 V/DC, min. 1 A) such
as a USB mains adapter. Once the product is supplied with voltage, a white LED lights
up on the front.
• The system starts automatically.

c) USB

The USB connection "USB" can be used to connect various USB mass storage devices.
For example, a USB drive or an external hard disc with music can be connected to play
back music from it.
