Specifications - Infinity 5000Cs Einbauanleitung
SPECIFICATIONS
S
PECIFICATIONS
5000cs
Type:
152mm (5-1/4") 2-Way Component System
Speaker Impedance:
4 Ohms
Power Handling:
75W RMS, 225W Peak
Frequency Response:
67Hz – 21kHz
Sensitivity (2.83V, 1m):
92dB
Crossover Frequency:
3.5kHz
Mounting Depth:
Woofer: 58mm (2-1/4")
Tweeter: 32mm (1-1/4")
Cut-Out Diameter:
Woofer: 120mm (4-11/16")
Tweeter: 47mm (1-13/16")
6000cs
Type:
163mm (6-1/2") 2-Way Component System
Speaker Impedance:
4 Ohms
Power Handling:
90W RMS, 270W Peak
Frequency Response:
53Hz – 21kHz
Sensitivity (2.83V, 1m):
92dB
Crossover Frequency:
3.5kHz
Mounting Depth:
Woofer: 53mm (2-1/16")
Tweeter: 32mm (1-1/4")
Cut-Out Diameter:
Woofer: 127mm (5")
Tweeter: 47mm (1-13/16")
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to change without notice.
Varaamme oikeuden teknisten tietojen ja tuotteen ominaisuuksien muuttamiseen ilman eri ilmoitusta.
- 4 -
6500cs
Type:
163mm (6-1/2") 2-Way Component System
Speaker Impedance:
4 Ohms
Power Handling:
90W RMS, 270W Peak
Frequency Response:
53Hz – 21kHz
Sensitivity (2.83V, 1m):
92dB
Crossover Frequency:
3.5kHz
Mounting Depth:
Woofer: 62mm (2-7/16")
Tweeter: 32mm (1-1/4")
Cut-Out Diameter:
Woofer: 142mm (5-9/16"142mm)
Tweeter: 47mm (1-13/16")
6800cs
Type:
153x204mm/127x178mm (6"x8"/5"x7")
2-Way Component System
Speaker Impedance:
4 Ohms
Power Handling:
90W RMS, 270W Peak
Frequency Response:
49Hz – 21kHz
Sensitivity (2.83V, 1m):
92dB
Crossover Frequency:
3.5kHz
Mounting Depth:
Woofer: 62mm (2-7/16")
Tweeter: 32mm" (1-1/4")
Cut-Out Diameter:
Woofer: 127mm x185mm (5"x7-1/4")
Tweeter: 47mm (1-13/16")
105t
Type:
25mm (1") Tweeter
Speaker Impedance:
4 Ohms
Power Handling:
50W RMS, 150W Peak
Frequency Response:
2.5kHz – 20kHz
Sensitivity:
91dB
Crossover Frequency:
3.5kHz
Mounting Depth:
31mm (1-3/16")
Cut-out Diameter:
45mm (1-3/4")
