Vaporesso Cascade One Kurzanleitung

Cascade One/Cascade One Plus Kit
Thank you for choosing Vaporesso Products!
Please read this manual carefully to ensure proper use. For additional information or questions regarding
to this product or its use, please visit www.vaporesso.com
Lid Pyrex glass tube
Drip tip
Coil Power button
Main features Package Include
● Revolutionary triangular air flow producing 1 x Cascade One/ Cascade One Plus Kit
a smoother, denser cloud. 1 x GT Mesh Coil 0.18Ω(50W-85W)
● Unique Isolation Structure, allowing consistent, 1 x GT CCELL2 Coil 0.3Ω(35W-40W)
intense flavors with every puff. 1 x Vaporesso USB Cable
● Safety lock mechanism, effectively avoid
accidently opening top cap and leaking e-juice.
Specification
Refillable Tank Capacity: Cascade One:2/3.5ml / Cascade One Plus:5ml
Built-in Battery Capacity: Cascade One:1800mAh / Cascade One Plus:3000mAh
Dimensions: Cascade One:22x22x121mm / Cascade One Plus:24.5x24.5x138mm
Weight: Cascade One:58g / Cascade One Plus:89g
Cascade One(Plus) is an excellent pen style starter kit for great vaping performance and portability.
Matched with ingenious design of Cascade Mini/Baby Sub-Ohm Tank is bringing unprecedented limit
enjoyment to you.
Unique Isolation Structure separates the coil and e-juice chamber, allowing consistent flavor with every
puff! Using the new groundbreaking GT Mesh Coil Technology, producing denser clouds and purer flavors
at a lower wattage! The 1800mAh-3000mAh built-in battery with 2A Quick charging system turns all-day
vaping into reality.
How to Use
1.Switching On/Off:Press the fire button 5 times in quick succession within 2 seconds to turn the device
on. Using the same way, the device can be powered off after 5 presses.
2.Vaping:Hold the fire button and inhale through the mouthpiece. Release the fire button and exhale.
3. Adjustment of Air Flow:The bottom airflow system can be adjusted by twisting the airflow ring.
4. Filling E-liquid:Lift and twist the top lid counter clockwise to the fullest extent. Add your favorite E-juice
through the opening and slide the lid back. Allowing the safety locking mechanism to secure the lid.
OPEN
5. Changing Atomizer:Remove base to unscrew the GT mesh coil and insert the new one. Secure the
base back onto the device. There are a variety of GT coils available for Cascade Tank series. Please
select the coil you desire.
OPEN
OPEN
6.Charging: Using the Quick Charge System. Simply plug in the USB cable to charge the battery. The
indicator light on your CASCADE ONE(PLUS) will turn red while it is charging. When it's fully charged, the
light will remain white.
Battery Protection
● If you vape for more than 10 seconds without stopping, the light will flash 3 times and shut itself down.
Quick Guide
● Short Circuit Protection: When the CASCADE ONE(PLUS) detects a short, the light will flash 5 times
and stop charging.
● Low Voltage Protection: When the voltage drops below 3.3V, the red light will flash 3 times and stop
charging.
● Overcharge Protection: The CASCADE ONE(PLUS) will stop charging once fully charged.
● No Load Protection: When the CASCADE ONE(PLUS) does not detect an atomizer, the light will flash 3
times.
Power Indicator
The indicator glows during use to reflect battery strength.
● Green = High (Above 70% power)
Adaptor
● Blue = Medium (30%-70% power)
● Red = Low (Below 30% power)
Caution
1. It is intended for usage by people over 18, NOT by non-smokers, children, pregnant or breastfeeding
women, people with or at risk of heart disease, or people taking medication for depression or asthma.The
electronic cigarette is not a smoking cessation device.
2. Please keep this unit out of reach of children or pets;
3. Please don't drop, throw or abuse your Mod,it may cause damage.
4. Do not place it in extremely temperatures;
5. Do not try to disassemble the battery.
Protection Functions
USB Input Protection / Equalizing charge system / Low voltage protection / Output short circuit
protection / Low resistance protection / Over-temperature protection / Overcurrent protection
Anti-loaded battery protection
Precautions:
1. Don' t use the device in stormy weather or dust condition.
2. Connect the USB port and charger properly. Unplug the charger when the charging is completed.
3. Don' t put the device in your pocket or handbag directly; don' t mix it with coins, jewelry or other hard objects.
4. The charger and battery may heat when charging, keep away from flammable gas, liquid or other
materials
This refillable electronic cigarette is intended for use with compatible liquid, which
may contain nicotine. Nicotine is an addictive substance and its use is not
recommended for use by the following:
- Non smokers or persons under the legal smoking age
- Pregnant or breastfeeding women
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term
throat disease or difficulty breathing due to bronchitis,emphysema or asthma.
CLOSE
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal
gland that can affect blood pressure)
- Those taking the medications Theophylline, Ropinirole or Clozapone
You may experience the following side effects if you use nicotine containing e-liquid in
combination with this product. If this happens, please consult a healthcare professional
and show them this leaflet if possible:
- Feeling faint / - Nausea /- Dizziness /- Headache /- Coughing
- Chest palpitation or an irregular heart rate /
- Irritation of the mouth or throat
- Stomach discomfort /- Hiccups /- Nasal congestion/- Vomition
CLOSE
Designed in California
Manufacturer:Shenzhen Smoore Technology Limited
Add:Building 8,Dongcai Industrial Park,Gushu Town,
Baoan District,Shenzhen, China 518102
Management System of SMOORE factory has been assessed
and registered under the Norm cGMP, ISO13485, ISO9001
and ISO14001.TM and ©2016 Vaporesso All rights reserved
This device should not be used by persons under the age of 18 or non-smokers.
