ENGLISH
Function
With the "set-back programmer" night set-back can be timer-
controlled. The timer is mounted in the transformer unit.
The timer is a digital 2-zone 7 day time switch with a circular
segmented display. Up to 4 programmed periods per day and
per setback-zone can be set.
The setback period is indicated by the dark segments ¢lay.
If no button is pressed for 60 seconds during programming the
time switch goes back to the start position. The copying function
enables programs to be copied to other days. Minimum switching
time is 1 minute. Programs are displayed with a minimum segment
size of 30 minutes. The time and the weekdays are presented
digitally.
The summer/ winter changeover can be programmed for manual or
automatic operation.
The setback-zone for each room is chosen by wiring the thermostat
to the terminal
1 or
2 in the connection box.
Presentation
Summer/winter
Real time, switching time
Clr = Clear switching times
SET TIME CHECK... ON
PROG DATE NEW...OFF
Copy = copy switching times
SU/Wi
Actual day of the week
or program day
18
1234567
Segment display of the
existing program
1 segment = 30 minutes
Button Menu
activates the menu or
MENU
breaks off the process
Button moves the flash
Button minus and plus
changes the values
Reset
RESET time Switching program remains
Pres
MENU
24
RESET all Switching program deleted
18
6
Press all 5 buttons together.
1234567
First release button
12
1 2
buttons.
1. Setting actual time
Button
MENU
SET TIME
Select SET TIME ... with
and confirm with
Confirm SET TIME ... once more with
Set actual hour with
and confirm with with
24
Set actual minute with
with
18
6
OK
1234567
12
1 2
4
INSTRUCTONS
Timer module FH-WN
Connection box with timer FH-WC
Menu
Day/month/year
D/M/Y
Symbol for automatic operation
24
Symbol for manual override
6
Symbol for continuous override ON
Symbol for continuous override OFF
12
1 2
Setback temperature
ON (Setback)
OFF (Comfort)
OK
Actual selected zone display
Button OK
confirms the input
together
, then let release all other
MENU
activates the menu.
.
OK
OK
and confirm
.
VI.SP.A1.8O
2. Setting actual date and summer/ winter changeover
SET
DATE
D/M/Y
SET
DATE
D/M/Y
3. Summer/winter changeover
SET
DATE
SU/Wi
Beginning of
Choice
summertime
Last Sunday
Euro
in March
Last Sunday
Gb
in March
1
ST
Sunday
US
in April
No
nonE
changeover
MAn
If manual changeover is required choose MAn during the date
input. Automatic changeover depends on your country/area.
Choose the appropriate setting for your country/area.
Freely programmable date with regard to the change from
summer time to winter time.
Northern Hemisphere
Put in the date at which the summer time starts and ends at your lo-
cation/ in your country. The weekday is automatically allocated to
the date.
Set year with buttons
Set actual day and month of summertime with buttons
.
and confirm with button
OK
Set actual day and month of real time with buttons and confirm with
button
.
OK
Produced by Danfoss Floor Heating Hydronics 01.2007
Press
.
MENU
Select SET TIME ... with
and confirm with
OK
Select DATE ... with
and confirm with
.
OK
Set year with
and confirm with
Set day and month with
.
OK
Summer-/winter changeover can be made
manually or automatically if set.
Choose the region of summer-/winter
changeover (see table below)
with buttons
.
Confirm with button
.
OK
End of
summertime
Last Sunday
in October
Fourth Sunday
in October
Last Sunday
in October
No
changeover
and confirm with buttons
.
OK
.
OK
and confirm with
Country /
area
EU
GB
Only North
America
.
OK
