XLOCK XLOCK182 Betriebsanleitung Seite 2

Instruction manual - EN
4. Packing
Packaging can be disposed
appropriate collection points - paper in the paper garbage can,
plastics in the yellow bag and glass in the used glass container.
5. EG - Declaration of Conformity
With the CE mark XLOCK, a registered trademark of datamobile,
declares that the product meets the essential requirements and
directives European regulations.
6. Packaging accessories
Lock
with 3 screws
7. Safety information
Minimum distance
To avoid interference
between the locks, keep
a minimum distance of
10 cm. The battery can
otherwise be quickly
discharged. Up to 15
meters with Bluetooth.
Storage
A minimum distance is also mandatory for storage. Do not insert
the battery until before commissioning.
Disposal
The locks contain electronic
components and belong in the electronic waste.
Mounting the lock
Tighten the screws with feeling and do not use drills
or cordless drill or cordless screwdriver.
8. Mounting instructions, APP installation ...
Errors and misprints excepted
© XLOCK,
of free of charge at
1x Screwdriver
Closing part (S2)
with 4 screws 1x Sticker
Please scan the QR code with
your Smartphone and a website
with all the information will open.
If you are working on a PC, you
can click on the QR code and a
website with all the information will
open.
XLOCK 182
the
1.Technical details
Dimensions (HxBxD)
Weight
Temperatur
Humidity
Bluetooth-Variante
RFID Frequenz
RFID-Standards
Battery
The Battery status
App / Cloud System
Size of memory
Read distance
2. Maintenance, care, storage and transport
ATTENTION!
Use only a dry and soft cloth for cleaning.
•
Do not use any cleaning agents or chemicals.
•
Store the product in a cool and dry place.
•
Store the product out of reach of children and in a dry and dust-
•
protected environment when not in use for a longer period of time.
Keep the original packaging for transport.
•
3. Disposal information
According to the European WEEE Directive, electrical and
electronic equipment must not be disposed of with household
waste. Their components must be recycled or disposed of
separately, because toxic and hazardous components can cause
lasting damage to
improperly. As a consumer, you are obliged under the Electrical
and Electronic Equipment Act (ElektroG) to return electrical and
electronic equipment free of charge at the end of its service life to
the manufacturer, the point of sale or to public collection points
set up for this purpose. Details are regulated by the respective
state law. The symbol on the product, the operating instructions
and/or the packaging
separating, recycling and disposing of old equipment in this way,
you are making an important contribution to protecting our
environment.
BLE, NFC, Gateway
Lock: 110 x 64 x 30 mm Locking part: 43 x 40 x
20 mm.
ca. 200 g (locking part, battery and
screws included in the set)
-10 °C to +55 °C (14 °F to 131 °F) (depending
on electronics and RFID frequency)
20% to 75% relative humidity, non-condensing
Bluetooth Low Energy(BLE), Nordic Chipset
13.56 MHz / NFC
ISO14443a, NFC, Mifare® Classic + Desfire
6V 2CR5 lithium battery. Up to 20,000 openings
and up to 2 years at +20 °C (68 °F). Run time
depends on temperature and use.
The battery status is displayed in the app.
Optionally, there is a message via e-mail.
XL Lock Manager APP, Webservice:
www.xlock.app; Made in Austria
Up to 200 RFID users, unlimited for XL
Lock Manager App users.
5 to 35 mm (0.2'' to 1.38'') depending on
RFID transponder quality, electronics,
antenna position, housing material and
mounting.
Up to 15 meters with Bluetooth.
health and the environment if disposed of
indicates these regulations. By
