CONNECTION
1 - SAFETY WARNINGS
ATTENTION! To ensure the safety of people it is important to follow these instructions and keep
them for future use. Carefully read the instructions before installing and performing the work as specified
by the manufacturer; check if the product is suitable for the desired type of use. The device must only be
intended for the use for which it was expressly designed. Installation, programming, commissioning and
maintenance of the equipment must only be carried out by qualified technical personnel, in compliance
with the mandatory regulations, including those for the correct disposal of packaging. Handle the
equipment with care, especially during installation, avoiding falls, knocks, or contact with liquids; do not
position the equipment near sources of heat; the presence of metallic structures may affect the radio
range. Before servicing the equipment, always remove the batteries from the device. The manufacturer
cannot be held liable for any damage resulting from improper or unreasonable use. ATTENTION: the
EGKTR1/EGKTR2 radio keypad is a battery-powered electronic device and the paired devices
cannot be activated if the batteries are flat. It is therefore recommended to provide for an
appropriate alternative actuation system.
The contents of this manual may be modified at any time without prior notice. The most up-to-date
version is available on the website www.keyautomation.com
2 - INTRODUCTION TO PRODUCT
EGKTR1/EGKTR2 is a digital keypad with capacitive touch technology. Its operating principle is similar to
that of a two-channel transmitter, and transmission occurs by keying in the user code followed by the
For all learning, deletion and function paring operations with the
EGKTR1/EGKTR2 is compatible with Key Automation control units and receivers.
NOTE - Each digital keypad has a unique serial number making it different from every other
keypad, each user code must be saved in the receiver and paired with the function that needs
to be carried out (see the radio receiver or control unit manual).
NOTE - The default (factory-set) master code for all keypads is 1 2 3 4. For safety reasons, this
code must be changed during installation.
2.1 - TECHNICAL CHARACTERISTICS
Base material
Power supply
Radio frequency
Max current
Battery life
Line of sight range
Number of code digits
Savable codes
Antenna
Operating temperature
Equipment class
Protection rating
Dimensions
Weight
(*1) The conditions of use being equal, the battery life can be significantly increased, even with respect to alkaline batteries,
using non-rechargeable lithium batteries (such as Energizer® Ultimate Lithium AAA or VARTA Ultra Lithium AAA).
(*2) The use of rechargeable batteries is strongly discouraged.
(*3) Installation on metal surfaces significantly reduces the maximum range.
EGKTR1/
brushed metal
MHz
mA
months
m
°C
IP
mm
gr.
or
channel, see the receiver manual.
3V – 2 x AAA
433,92
200
(red colour, maximum brightness level)
12
60 max
From 3 to 6
(factory-setting = 4 digits)
fino a 20
Built-in
-10 +55
III
55
79 x 79 x 23
226
EGKTR2
plastic
(*1) (*2)
(*3)
(h)
100
EN
or .
7
