STEP 2 Attach Wall Plate to Wall
For wood stud installations, follow STEP 2A on PAGE 8
For concrete installations, follow STEP 2B on PAGE 12
Parts and Hardware for STEP 2
WARNING:
This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;
contact Customer Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
Wall Plate Template
12
x1
Wall Plate
13
x1
Lag Bolt
14
x4
5⁄16 in. x 2 3⁄4 in.
Concrete Anchor
For Concrete Installations ONLY
CAUTION: Do not use in drywall or wood
15
x4
UX10 x 60R
