MODECOM
2.0 MONITOR SPEAKERS
Introduction.
MODECOM Eclipse speaker set was designed for those seeking uncompromised audio
experience. Its high-class components and features provide excellent sound performance.
Sound control panel was placed on the top of one of the speaker.
Specification.
Dimensions: 357x240x220mm [Eclipse 180], 255xl 90x160mm [Eclipse 60]
Drivers: 6.25" + 1.4" [Eclipse 180], 3.6" + 1.4" [Eclipse 60]
RMS power: 180W (55W+35W) x 2 [Eclipse 180], 60W (20W+10W) x 2 [Eclipse 601
Frequency response: 35Hz-22kHz [Eclipse 1801 , 55Hz-22kHz [Eclipse 60]
Signal input: 2 x RCA, 1 x optical, Bluetooth with Apt-XTM lossless audio (for com
patible devices)
IntersilTM D2-41051 chipset with Class-D amplifier
Power AC 110V-240V
Net weight:
Package content: optical cable, RCAx2 cable, power supply cable, speakers con
necting cable, remote controller with battery.
Installation.
Before you begin the installation make sure that the main power switch is in OFF . Place
the speakers such that the active speaker is on the right side. To achieve best stereo effect
listener and satellite speakers should form equilateral triangle (each satellite should be in the
same distance from the listener's ears). Preferably try to put the speakers in such manner that
the tweeter speakers are on the same height as your ears.
Connect the signal cable with the Mini-Jack 3.5 mm plug or Optical to the appropri-
ate output port of your sound source (for example output of your PC's soundcard).
Connect the cable to the "L-SPK OUT" on the back of the active speaker and to the
2.
similar socket on the back of left speaker.
3. Connect the power plug to the mains socket.
4. Switch main power switch to ON position.
5. Short press Standby/lnput button on the control panel. After turned on the default
audio source is Bluetooth (BT). Press Standby/lnput button to switch between
sound sources: AUX (2xRCA) and OPT (optical). Press and hold Standby/lnput
button for 3s to enter sleep mode. You may also set audio source by pressing Input
button on the remote.
To connect via Bluetooth set the sound source to BT position and press and hold 3s
6.
Pairing/Mode button on the control panel. You will hear a short tone and the LED will
begin to flash —speakers are ready for pairing. Find and select the speakers on the
list of available devices of your smartphone or tablet. If you will be asked to provide
a passcode input 0000. When pairing is completed the LED will stop flashing. If you
wish to pair with another device repeat step 6. When turned on again or selecting
BT input again the speakers will attempt to connect to the last paired audio source
automatically if the Bluetooth mode will be enabled in your device. You may also
www.
ECLIPSE
SYSTEM
50/60Hz
kg [Eclipse 180], 3kg [Eclipse 60]
modecom
EN
. eu
