Automatischer  Entkuppler
Automatic  Uncoupler
84140xx
Wichtige  Information  zur  Inbetriebnahme
Important  setup  information

Werbung

loading

Inhaltszusammenfassung für Massoth 84140 Serie

  • Seite 1 Automatischer  Entkuppler Automatic  Uncoupler 84140xx Wichtige  Information  zur  Inbetriebnahme Important  setup  information...
  • Seite 2 FREILANDTAUGLICHKEIT SUITABILITY  FOR  OUTDOOR  USE Sehr  geehrte  Kunden,  immer  wieder  errei- Dear  customer,  we  have  received  a   chen  uns  Anfragen  bezüglich  „rostender   number  of  enquiries  about  rusty  screws   Schrauben“  bei  Komponenten,  die  im   in  components  that  are  used  outside  and   Außenbereich  der  alljährlichen  Witterung  ...
  • Seite 3 WICHTIG:  Bitte  lesen  Sie  diese   IMPORTANT:  Please  read  this  ma- Bedienungsanleitung  vor  Inbetrieb- nual  thoroughly  before  unpacking,   nahme  gründlich  durch. installing  or  using  this  product. 1.   Einleitende  Information 1.   General  Information Der  Automatische  Entkuppler  ent- The  Automatic  Uncoupler  disen- kuppelt  einen  angehängten  Zug  per  ...
  • Seite 4 2.   Wichtige  Informationen   2.   Important  information zur  Inbetriebname Der  Entkuppler  wird  aus  Gründen   For  transport  safety  reasons  the   der  Transportsicherheit  komplett   Uncoupler  comes  fully  assem- montiert  ausgeliefert.  Für  die  Monta- bled.  To  install  the  Uncoupler  it  is   ge  wird  die  Antriebseinheit  des  Ent- necessary  to  dismantle  (2  screws)  ...
  • Seite 5 Mechanikeinheit mechanical  unit Antriebseinheit drive  unit Abbildung  1:  Vorbereitung  des  Automatischen  Entkupplers  zur  Montage Illustration  #1:  Preparing  the  Automatic  Uncoupler  for  installation...
  • Seite 6 3.2   M ontage 3.2   I nstallation  &  Assembling Der  Entkuppler  verfügt  über  die   The  Uncoupler  has  the  standard   standardisierte  Kupplungsaufnahme,   wie  sie  bei  Groß-  und  Gartenbahnen   standard  for  G-Scale  (LGB ,  etc.).   ® (LGB ,  etc.)  üblich  ist.
  • Seite 7 Antriebseinheit drive  unit Mechanikeinheit mechanical  unit Abbildung  2:  Montage  des  Automatischen  Entkupplers  an  gewünschten  Lok Illustration  #2:  Mouting  the  Automatic  Uncoupler  to  the  locomotive...
  • Seite 8 ®  Onboard  Decoder  (groß)  DCC  Interface  Board ® ®  DCC  Schnittstellenplatine MASSOTH  Onboard  Adapter ® MASSOTH  Onboard  Adapter Always  make  sure  you  read  the   Beachten  Sie  hierbei  immer  die   documentation  of  the  decoders  and   Dokumentation  der  verwendeten  ...
  • Seite 9 LGB  Onboard  Decoder (groß  /  large) LGB  DCC  Interface MASSOTH  Onboard  Adapter Abbildung  3:  Anschluss  des  Entkupplers  an  Decoder  und  Schnittstellenplatinen Illustration  #3:  Connecting  the  Uncoupler  to  decoders  and  interface  boards...
  • Seite 10 4.2   A nschluss  ohne  Stecker 4.2   W iring  the  Uncoupler  directly Bei  Decodern  mit  Klemm-  oder   Other  decoders  will  require  wiring   Lötanschluss  schneiden  Sie  den   via  clamps  or  soldering.  Cut  off  the   3poligen  Stecker  ab  und  schließen   plug  attached  to  the  cable  and  wire  ...
  • Seite 11 5.   Inbetriebnahme   5.   Commissioning   5.1   E instellungen 5.1   S ettings Programmieren  Sie  den  ange- Program  the  connected  function   schlossene  Funktionsausgang   output  to  the  preferred  function  key.   auf  die  gewünschte  F-Taste.  Der   The  function  output  must  not  be  ...
  • Seite 12 ten  das  man  nicht  mit  abgesenktem   lowered  hook. Haken  fährt. Uncoupling  should  only  be  executed   Das  Entkuppeln  sollte  immer  ohne   in  a  stationary  position  without  load   Last  erfolgen.  Rangieren  Sie  die   on  the  Uncoupler.  Always  position   Lok  und  Wagen  so,  das  sich  die  ...
  • Seite 13 6.   Lokaufstellung 6.   List  of  Locomotives Diese  Tabelle  zeigt  eine  Über- This  table  shows  the  compatibility  of   sicht  verschiedener  Lokmodelle   the  Uncoupler  with  various  locomo- unterschiedlicher  Hersteller  und   tives  of  several  manufacturers.  The   informiert  über  die  Montierbarkeit   table  shows  the  basic  item  number  ...
  • Seite 14 Loktyp Bezeichnung 20310 DB  101  E-Lok DB  101  Electric  Loco 20330 Rottenlok Maintanance  Loco 20350 Straßenbahn Historic  German  Street  Car 20380 US  Straßenbahn US  Street  Car 20390 RhB  ABe  4/4  32  Triebwagen RhB  ABe  4/4  32  Rail  Car 20400 RhB  Ge  6/6  I  Krokodil RhB  ABe  6/6  I  Crocodile 20410 RhB  Tm  2/2  25  Schienentraktor...
  • Seite 15 Loktyp Bezeichnung 20710 U-Reihe U-Series 20720 U-Reihe U-Series 20730 U-Reihe U-Series 20740 Spreewald Spreewald 20760 DR  99  5001  Steam  Loco 20780 Corpet  Louvet Corpet  Louvet  Steam  Loco 20790 Corpet  Louvet Corpet  Louvet  Steam  Loco 20800 HSB  99  6001  Steam  Loco 20810 HSB  99  7222  Steam  Loco 20840...
  • Seite 16 This  table  is  not  exhaustive.  Errors  accepted.   (auch  variantenbezogene  Modellabwei- variations  may  effect  compatibilty.  The  latest   chungen,  etc.)  sind  vorbehalten.  Eine  aktuelle   list  of  compatible  locomotives  can  be  found  at   Lokaufstellung  erhalten  Sie  jederzeit  auf  www. the  website  www.massoth.de  any  time. massoth.de.
  • Seite 17: Operating Voltage

    7.   Technische  Daten 7.   Betriebsspannung   Operating  Voltage 16  -  22  Volt  DC  (kein  DCC) 16  -  22  Volt  DC  (no  DCC) Stromaufnahme   Power  consumption   200mA  (Motor) 200mA  (motor) 3mA  (Schalteingang) 3mA  (function  input) Betriebstemperatur Operation  temperature -20...50°...
  • Seite 18 7.1   G arantie,  Reparatur,  Kundendienst 7.1   W arranty,  Service,  Support MASSOTH  gewährt  die  Fehlerfreiheit   MASSOTH  warrants  this  product   dieses  Produkts  für  ein  Jahr.  Die   against  defects  in  materials  and   gesetzlichen  Regelungen  können  in  ...
  • Seite 19 7.2   H otline 7.2   H otline Serviceanfragen  richten  Sie  bitte  an For  technical  support  please  contact Massoth  Elektronik  GmbH Massoth  Elektronik  GmbH Montags  von  14:00-17:30 Mo  2:00-5:30  p.m.     Donnerstags  von  8:00-12:00 Thu  8:00-12:00  a.m. FON  +49  (0)6151-35077-38 FON  +49  (0)6151-35077-38...
  • Seite 20 Massoth  Elektronik  GmbH QUALITY Frankensteiner  Str.  28  ·∙  D-64342  Seeheim  ·∙  Germany MADE IN FON:  +49  (0)6151-35077-0  ·∙  FAX:  +49  (0)6151-35077-44 GERMANY eMail:  info@massoth.de  ·∙  www.massoth.de...
