Hard Drive Installation
For first time installation, please prepare a 3.5-inch hard disk drive (HDD). It is
recommended to use the HDD of enterprise or surveillance level. Before installation,
please disconnect the power from the network video recorder (NVR).
1� Remove the fixing screws on the side and back panels to open the cover of the
NVR.
2� Attach the 4 included HDD screws to your hard drive. Do not fasten.
3� Match the 4 screws on the HDD with the 4 holes on the NVR, and insert the HDD
interface into the slot.
Hard Disk Drive (HDD)
