Olymp LavaSit DINER Montageanleitung Seite 6

Mounting instructions for appliance fitters
14. Assembly:
14.1 Loosely bind the 2 pressure hoses (hot + cold) and
drain hose together using cable ties.
14.2 Hang the backside cover (1) onto the base:
Hold the cover at the front edge from both sides,
pull apart and draw it from the rear side onto the
base: Front edge of cover must engage in
perpendicular profile.
14.3 Put in the front cover (2) under the seat.
14.4 only with in-line installation:
Attach mounting strips (5) for installation tunnel
onto the backside cover over the cutout at both
units (fig. 2).
Lay the installation tunnel onto the mounting strips.
Caution:
The ends of the installation tunnel must be fitted
with edge protection!
