swing2sleep Gestell Montageanleitung Seite 5

Single frame
Assembly instructions
Assembly
1x 1x
Lower bracket Lower bracket
8x 4x
Cover cap Spacer
4x 1x
4x
Adjustable foot Pig Tail Hook
+ Anti-slip pad
optional accessories:
Velcro cable tie for attaching the power supply
unit or extension cable to the frame.
1.
1x
Top bracket
9x
Flat wascher
1x
Star knob
1
2x
middle tube
5x 4x
Nut
4x 1x
Grub screw
(already screwed
into the frame)
Video instructions
for frame assembly
Loosen the four pre-assembled grub screws
with the hex key
2
3
EN
2x
Cover cap lower
bracket
(possibly already
pre-assembled)
Hexagon head
screw with shaft
Hex key
4
