smooth direction changes need practise but should be a skill all pilots
have mastered.
Please note: if the paraglider is no longer steerable using the brake
lines (for example if they have become tangled) then the wing has
limited steering capacity through the C-risers.
This, in combination with weight-shift, still allows reasonable turn
correction. Using this technique also permits a safe landing. The
C-risers should not be pulled so hard that they cause the wing to stall.
The Speedbrake Riser can also be used to steer the glider.
Landing
Landing the PHANTOM is very simple. In turbulent conditions it is ad-
visable to make your approach whilst pulling a little brake in order to
increase stability and to increase the feeling for the wing's movement.
!
Immediately before touchdown the brakes should be pulled hard –
even to the point of stall.
Please note: a full
stall – if initiated too
Rapid descent techniques
early – can lead to
heavy landings
To quickly lose height, we recommend three possible manoeuvres. We
or even serious
have ordered these by degree of difficulty:
accidents. Therefore
the brakes should
only be pulled fully
1) Big ears
immediately before
touching the ground
To use big ears, both outer A-lines (fitted on a separate riser – split
(<0.5 meters).
A-risers) should be pulled down simultaneously. The brake handles (wi-
thout an additional wrap) remain in your hands. As long as the lines are
held down the wingtips remain folded and this increases the sink rate.
If the speed bar is used as well, this increases sink and speed. This
also equalises the higher angle of attack caused by the increased drag
of the ears.
To release the ears, release the A-lines fully and allow them to return to
their normal flying position. If the ears do not open automatically, the
pilot can use a quick, sharp tug on the brakes to assist the opening.
2) B-line stall
A B-line stall is instigated by symmetrically pulling both B-risers
(approximately 15 centimetres). It is recommended – for maximum
grip as well as safely executing the manoeuvre – to grab the risers at
the top. i.e. at the maillon.
Immediately after pulling the risers, the wing will lose its forward speed
and after a short oscillation will descend in a stable parachutal stall.
The B-line stall is released by simultaneously raising your B-risers
back to their normal flying position. If they are released too slowly, an
unintended consequence can be a parachutal stall (see the section on
parachutal stall).
The brakes should remain in your hands the entire duration of the
manoeuvre and no additional wrap should be taken. When exiting the
B-line stall it is important that the brake is completely free so that the
wing can fully accelerate to trim speed.
Please note: Particularly when the PHANTOM is heavily loaded, the
trailing edge can have a tendency to flutter, often accompanied with
unstable pitch. This makes it difficult to hold the B-line stall. In this
case, the B-line stall is not recommended as a descent technique.
3) Spiral dive
The spiral dive is the most demanding descent technique and should
be learned at great height, preferably during an SIV/pilotage course.
The manoeuvre has two phases:
• First the pilot weight-shifts into the turn and then uses the inner bra-
ke to induce an ever tightening turn (note: do not jerk the brake, but
pull it smoothly and continuously). With increasing acceleration, the-
re will be a moment where the G-forces rapidly increase and the nose
of the glider begins to point to the ground until (during a successfully
performed spiral dive) the nose is nearly parallel with the ground.
• At this point the wing will reach sink rates of 20 meters per second
(m/s) or more. The acceleration can be more than three times gravita-
tional force (>3g). The pilot must be aware of these forces.
Before learning to spiral, pilots should practise controlled exits from
steep turns. These exits are performed by using the outer brake,
whilst the inner brake initially remains in the same position. The ou-
_59
_EN
These physical
demands can be
simulated in a g-force
trainer. We recom-
mend such g-force
training to all pilots.
