Spare parts list

Cooling system:

Part.no.:
description
Refrigerant components:
Compressor NEK6210Z
High pressure switch HD 16-20bar
Electronic components:
Temperature controller board R23
Temperature controller display
Temperature probe PT100
Micro fuse 0,1A
Micro fuse 0,4A
Micro fuse 4,0A
Mechanical components:
Immersion pump T201
Fan
Float switch
Flow controller VTY
Other components:
Wire mesh filter 315x270x10
Filter case
Filter cartridge
Note: When replacing the board from
R02 to R23, the display must be replaced.
H.I.B Hydac International
Version: B
Datum : 05.05.2015
RK/W-01000-L-R23-SON-3-IW
3758272
Part. No.
new
3755777
3756246
3804698
3756766
3754818
3755532
3755514
3896412
3754705
3755756
3755184
3754664
3754512
3753833
3754609
