Technical Data - Rodcraft Rc2203 Bedienungsanleitung

Safety Information

Technical Data

Free speed (rpm)
Max. torque (reverse) (Nm)
Max. working torque (Nm)
Weight (kg)
Declarations
EU Declaration of Conformity
We, Desoutter GmbH, Edmund-Seng-Str. 3-5,
63477 Maintal, Germany, declare under our sole
responsibility that the product (with name, type,
and serial number, see the front page) is in con-
formity with the following Directive (s):
2006/42/EC (17/05/2006)
Harmonized standards applied:
EN ISO 11148-6:2013
Authorities can request relevant technical infor-
mation from:
Pascal Roussy, R&D Manager, Ets Georges Re-
nault, 38 rue Bobby Sands, BP10273 44818
Saint Herblain, France
Saint-Herblain, 24/03/2020
Pascal ROUSSY
UK Declaration of Conformity
We, Desoutter GmbH, Edmund-Seng-Str. 3-5,
63477 Maintal, Germany, declare under our sole
responsibility that the product (with name, type
and serial number, see front page) is in conform-
ity with the following UK Regulation(s):
Supply of Machinery (Safety) Regulations 2008
Designated Standards applied:
EN ISO 11148-6:2013
Saint-Herblain, 24/01/2022
Pascal ROUSSY
Authorities can request relevant technical information from:
UK Authorized Representative:
Air Compressors & Tools Ltd
Zodiac – Unit 4, Boundary way
Hemel Hempstead Industrial Estate, HP27SJ Hempstead
Hertfordshire – UK
Contact: M.Taylor
Noise and Vibration Declaration Statement
• Sound pressure level 90 dB(A) , uncertainty 3 dB(A), in
accordance with ISO 15744.
6
RC2203
10500
650
450
1.1
Signature
Signature
© Rodcraft - 8956001943
• Sound power level 101 dB(A) , uncertainty 3 dB(A), in
accordance with ISO 15744.
• Vibration total value 11.2 m/s
accordance with ISO-28927-2.
These declared values were obtained by laboratory type test-
ing in accordance with the stated standards and are suitable
for comparison with the declared values of other tools tested
in accordance with the same standards. These declared values
are not adequate for use in risk assessments and values mea-
sured in individual work places may be higher. The actual ex-
posure values and risk of harm experienced by an individual
user are unique and depend upon the way the user works, the
workpiece and the workstation design, as well upon the expo-
sure time and the physical condition of the user.
We, Desoutter GmbH, cannot be held liable for the conse-
quences of using the declared values, instead of values re-
flecting the actual exposure, in an individual risk assessment
in a work place situation over which we have no control.
This tool may cause hand-arm vibration syndrome if its use is
not adequately managed. An EU guide to managing hand-arm
vibration can be found by accessing
index.php and selecting 'Tools' then 'Legislation'.
We recommend a programme of health surveillance to detect
early symptoms which may relate to noise or vibration expo-
sure, so that management procedures can be modified to help
prevent future impairment.
If this equipment is intended for fixtured applications:
The noise emission is given as a guide to the machine-
builder. Noise and vibration emission data for the com-
plete machine should be given in the instruction manual
for the machine.
Regional Requirements
WARNING
This product can expose you to chemicals including lead,
which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more
information go to
https://www.p65warnings.ca.gov/
Safety
DO NOT DISCARD - GIVE TO USER
WARNING Read all safety warnings, instructions, il-
lustrations and specifications provided with this prod-
uct.
Failure to follow all instructions listed below may result
in electric shock, fire, property damage and/or serious in-
jury.
Save all warnings and instructions for future refer-
ence.
WARNING All locally legislated safety rules regard-
ing installation, operation and maintenance shall be
respected at all times.
Statement of Use
• For professional use only.
Impact Wrench
2 2
, uncertainty 4.1 m/s , in
http://www.pneurop.eu/
