axing premium CMO 2-01 Kurzanleitung Seite 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
EU Declaration of Conformity
Hereby, AXING AG declares that the device is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet
address:https://axing.com/downloads/ce/.
WEEE Nr. DE26869279 | Electrical and electronic components must not be disposed of
as residual waste, it must be disposed of separately.
State of the art 2021-12-17
Technical improvements, changes in design, printing- and other errors reserved.
Technical data:
Type
Downstream
Frequency range
Channel bandwidth
Channel bonding
Input level
Demodulation
Data rate Max. 320 Mbps @ DOCSIS
Max. 400 Mbps @ EuroDOCSIS
Upstream
Frequency range
5...65 MHz @ EuroDOCSIS
Channel bandwidth 200/400/800/1600/3200/6400 KHz
Output level
8...53 dBmV @ S-CDMA
Channel bonding
Modulation QPSK, QAM8, QAM16, QAM32, QAM64, QAM128
Data rate
Interfaces
Ethernet 2 × RJ 45, IEEE 802.3 10Base-T | 802.3u 100Base-TX |
802.3ab 1000Base-T (GigE)
WiFi standard IEEE 802.11b/g/n | 2.4 GHz single-band
Wifi signal rate
WiFi encryption
General
Operation voltage
Operating temperature range
Operating humidity (non-condensing)
Dimensions (W × H × D) appr.
Note: You can find the complete technical data at www.axing.com.
Commission regulation (EU) 2019/1782
External plug-in power supply
Manufacturer's name or trademark Shenzhen Click Technology Co., Ltd.
Fl 1-4 Building 7 and Fl 2 Building 8
commercial registration number and
Zhengzhong Ind Park, Qiaotou Village, Fuyong Town,
address
Guandong 518103, P. R. China
Model identifier
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Load condition 1 – 100 % ± 2 %
Load condition 2 – 75 % ± 2 %
Load condition 3 – 50 % ± 2 %
Load condition 4 – 25 % ± 2 %
Efficiency at low load (10 %)
No-load power consumption
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
CMO 2-01
108...1002 MHz
6 MHz @ DOCSIS
8 MHz @ EuroDOCSIS
≤8
-15 dBmV...+15 dBmV
QAM64, QAM256
CMO 2-01
5...42 MHz @ DOCSIS
premium-line
8...58 dBmV @ QPSK
8...54 dBmV @ 64 QAM
8...54 dBmV @ 32 QAM
DOCSIS/EuroDOCSIS
≤4
(SCDMA)
cable modem
120 Mbps @ TDMA
160 Mbps @ S-CDMA
WiFi
300 Mbps
Quick start guide
WPA/WPA2
12 VDC
0...40 °C
10...90%
167 × 125 × 38 mm
Boan District, Shenzhen
914403007576217064
CPSO24C120150V
100...240 V
50...60 Hz
12,0 V
1,5 A
18,0 W
84,1 %
85,1 %
86,3 %
86,0 %
82,2 %
0,04 W
