Pressalit PLUS R4650 Montageanleitung Seite 16

R4650
340 200 200
(13.39) (7.87) (7.87)
200
(7.87)
Ø32 (1.26)
340
153
(13.39)
(6)
Ø32 (1.26)
260
(10.24)
Ø32 (1.26)
153
340
(6)
(13.39)
200
(7.87)
22
