DPX
160 and 250 common auxiliaries and accessories
3
4 210 58
Supply invertor type
Pack
Cat.Nos
Plate for mounting and interlocking of 2 DPX
For 2 DPX
1 DPX
250
3
1
4 210 58 For fixed version
4 210 59 For plug-in and draw-out version
1
Rotary handles
Direct on DPX
1
4 210 00 Standard handle for thermal magnetic DPX
earth leakage module
1
4 210 01 Standard handle for electronic DPX
earth leakage module
1
4 210 02 Handle for emergency use for thermal magnetic
DPX
without earth leakage module
3
1
4 210 03 Handle for emergency use for electronic DPX
or with earth leakage module
Vari-depth handles
For all version of DPX
1
4 210 04 Standard handle
1
4 210 05 Handle for emergency use
Locking accessories
1
4 210 06 Key barrel and flat key N° ABA90GEL6149
for direct handle
1
4 210 07 Key barrel and star key N° HBA90GPS6149
for direct handle
1
4 210 08 Key barrel and flat key N° ABA90GEL6149
for vari-depth handle
1
4 210 09 Key barrel and star key N° HBA90GPS6149
for vari-depth handle
Motor-driven handles
Motor operators 24 to 230 VA/ =
4 210 60 Side motor operator
1
1
4 210 61 Front motor operator
Locking accessories
1
4 210 62 Key barrel and flat key N° ABA90GEL6149
for front motor operator
1
4 210 63 Key barrel and star key N° HBA90GPS6149
for front motor operator
4 210 64 Padlock for front motor operator
1
1
4 210 65 Key barrel and flat key N° ABA90GEL6149
for side motor operator
1
4 210 66 Key barrel and star key N° HBA90GPS6149
for side motor operator
1
4 210 67 Padlock for side motor operator
134
3
160 or 2 DPX
3
250 or 1 DPX
3
160 and
and/or with
3
3
4 210 00
Pack
Cat.Nos
3
1
4 210 10 1 N/C + 1 N/O auxiliary contact for rotary handles
1
4 210 11 Auxiliary contact or fault signalling contact
1
4 210 48 Signalling contact plugged-in / drawn-out (for DPX
4 210 12 12 VA/ =
1
4 210 13 24 VA/ =
1
without
3
4 210 14 48 VA/ =
1
1
4 210 15 110-130 VA
1
4 210 16 200-277 VA
4 210 17 380-480 VA
1
3
and/
4 210 18 12 VA/ =
1
4 210 19 24 VA/ =
1
4 210 20 48 VA/ =
1
4 210 21 110-130 VA/ =
1
1
4 210 22 200-240 VA
4 210 23 277 VA
1
1
4 210 24 380-415 VA
1
4 210 25 440-480 VA
1
4 210 49 Padlock for locking in "open" position
RS 485 communication interface
p. 146
4 210 10
4 210 11
4 210 16
4 210 22
Auxiliaries
Auxiliary contacts
plug-in version)
Shunt releases
Undervoltage releases
Locking accessory
