EN
28 | Additional functions
End of battery life
To signal the end of the device life, the battery symbol appears in the
display (permanent notification) and the error message Err09 is shown.
This message is displayed if the end of battery life stored in the system as
"Time until display of warning symbol" has expired. Also if an early and
unexpected voltage drop of the battery is detected. Battery lifetime
warning symbol plus error code Err02 will be issued
Attention! Device must be replaced!
Additional functions
Functions which are described below can only be used by means
of a communication head (KoKo) and appropriate PC configuration
software.
Programming with communication head
(available as accessory)
An inductive device interface is located in the middle of the housing,
directly on the printed circuit board beneath the display
A particular communication head (KoKo), a laptop computer / PC with a
USB connector and an appropriate configuration software is necessary
to communicate with the interface
480 Daily Final Values
With a command 480 daily final values can be read out by using the
communication head (KoKo).
Resolution in litres.
Elektronischer Wohnungswasserzähler
Error Logfile
An integrated rolling error logfile with maximum 10 entries allows
the storage of error messages This can help for analysis of problems
If more than 10 error messages occurred the oldest ones, probably
important ones, will be overwritten. Thus additional statistic data will
be saved (example):
Error
Timestamp of first
Registration
occurrence of error
Number
plus meter reading
03
14 03 2017,
15:43:22 Uhr
4256,354 m3
Radio Settings
As soon as the radio operation mode is activated, the meter sends an
encrypted radio telegram according to OMS (Open Metering Standard):
Telegram in C1 mode: Current value + last 15 monthly values.
If other radio settings and/or other radio telegrams are requested,
changes can be made by means of a communication head (KoKo)
and a configuration software.
Term
Individual
Factory
Settings
Setting
Days of transmission
0–127
30 days
since due date
Days of transmission
0–31
31 days
since beginning of
month
Days of the week
Monday to
Monday to
Sunday
Friday
Month transmission
January until
All months
December
Hour of transmission
0–23
6 a m to
7 p m
Interval of transmission 10 sec. up to
1 min
4h 30min
EN
English | 29
Timestamp of last
Number error
occurrence of error
occurred
plus meter reading
27 04 2017,
14
20:19:31 Uhr
5132,337 m3
Remark
Days without transmission will not be
added
Only days until end of month will be
added, but not days without
transmission
Every day of the week can be selected
separately Radio transmission on
weekends can be prevented
Every month can be selected
separately
Every Hour can be selected separately
for every day of transmission, starting
with selected time.
-
