EN
26 | Operation
Radio Settings
As soon as radio operation mode is activated, the meter sends an
encrypted radio telegram according to OMS (Open Metering Standard):
Telegram in C1 mode:
Current value + last 15 monthly values.
Standard radio settings:
A radio signal is sent starting on the first day of the month, for 5
working days, Monday to Friday from 6:00 a m to 8:00 p m in
intervals of one minute
If other radio settings and/or other radio telegrams are requested,
changes can be made by means of a communication head (KoKo)
and configuration software (see paragraph "Additional Functions").
Device Display Loop
Depending on the factory device configuration, the display shows different
values. Here is a typical example of a consumption at the last due date:
Device display
Display time
Example
10 s
Consumption
236,214 m³
Current flow 15 l/h
4 s
Consumption at the
last due date 175 m³
Check number c91
Due date 31 12
1 s
Segment-test "ALL OFF"
1 s
Segment-test "ALL ON"
Elektronischer Wohnungswasserzähler
Error Messages
If an error occurs, an error message is displayed The error message
will be integrated into the device display loop for one second
Error codes Err01 to Err07 are additionally transmitted with the
radio telegram
No.
Type
Description
Err01
System error
Memory error,
Detection out of order
Err02
BatLow
Battery voltage too low
Err03
Manipulation
Attempt to defraud
Err04
Transmission
Meter is unable to transmit data
error
Err05
Pipe burst
Detection of an extremely high
consumption during a long time
Err06
Leakage
A nearly permanent water flow in 24
hours which did not stop for at least
1-2 hours raises the suspicion of a
permanent water loss
Err07
Q
error
Detection of an improper high flow
max
which may damage the meter
Err08
Backflow error
Wrong direction of flow
Err09
Battery end
End of the device lifetime
EN
English | 27
1 sec
10 sec
Remark
Replace device
Replace device
Meter no longer valid
for billing
Check device
Check water network
Check water network for
leaks
Check water network
Check water meter
installation
Replace device
