CO/Tech 54100 Bedienungsanleitung

Surge Protector
Art.no 36-5994
Please read the entire instruction manual before using the product and then save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
In the event of technical problems or other queries, please contact our Customer Services.
Safety
• The surge protector must only be plugged into to an earthed 230 V, 50 Hz power outlet.
• Ensure that any appliance/s connected to the surge protector are rated for use with the correct
mains supply voltage (230 V, 50 Hz).
Operation
Note:
The surge protector is designed to suppress overvoltages in a domestic electrical system.
The surge suppression feature will not protect against very close or direct lightning strikes.
1. First check that the appliance to be connected to the surge protector is turned off.
2. Plug the appliance into the socket of the surge protector.
3. Then plug the surge protector into a wall socket.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.
Specifications
Max load
Max overvoltage
Max current spike
Outlet L-N
Outlet L-E
Outlet N-E
Max energy uptake 119 joules pulse for 10/1000 μs
Reaction time
IP rating
Size
Weight
GREAT BRITAIN • CUSTOMER SERVICE contact number 020 8247 9300
e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
Model 54100
230 V AC, 50 Hz, 16 A (3680 W)
6000 V
4500 A pulse for 8/20 μs
4500 A pulse for 8/20 μs
4500 A pulse for 8/20 μs
4500 A pulse for 8/20 μs
< 1 ns
IP44
55 × 85 × 120 mm
131 g
