Surge Suppressor
Art.no. 36-1258
Please read the entire instruction manual before using the product and save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
If you have any questions regarding technical problems please contact our Customer Services.
Safety
• The surge suppressor should only be connected to an earthed indoor wall socket.
• Check that all connected devices are rated at the same mains supply voltage (230 V 50 Hz).
Note! The surge suppressor's switch should be in the on position I and be lit for the outlets to carry current
and be operational.
Note! The green (PROTECT) indicator must be lit in order for the surge suppressor feature to be operational.
If the green (PROTECT) indicator does not light, this indicates that the surge suppressor feature is no longer
operational. The device will continue to function as a standard extension lead but no surge protection will be
provided to any connected devices.
Product description
• The surge suppression feature is designed to protect connected devices during e.g. thunder storms.
Note! The surge suppression feature will not protect against near or direct lightning strikes.
• Safety shuttered.
• Equipped with two varistors, a gas discharge tube and two fuses.
• Protection status indicator.
• On/off switch. Turns the outlets on and off.
• Wall bracket.
Operating instructions
1. Check that all devices to be connected to the surge suppressor are first turned off.
2. Check that the surge suppressor's switch is also turned off (O) before plugging the devices into the sockets
in the surge protector.
3. Plug the surge suppressor into a wall socket.
4. Switch the surge suppressor's power switch to the on position I. The switch and green (PROTECT)
indicator should be lit.
5. Switch on the connected device/s.
Disposal
This product should be disposed of in accordance with local regulations. If you are unsure how to proceed,
contact your local authority.
Specifications
Max load
Type
Uoc
Max overvoltage
Max current spike
Max energy uptake
Reaction time
Lead
GREAT BRITAIN • CUSTOMER SERVICE contact number 08545 300 9799
e-mail customerservice@clasohlson.co.uk internet www.clasohlson.com/uk
Model EMP416S
230 V AC, 50 Hz, 16 A (3,680 W)
lll
P-N = 2.5 kV P/N-E = 5.0 kV
6,000 V
Outlet L-N: 4,500 A pulse for 8/20 μs
Outlet L-E : 4,500 A pulse for 8/20 μs
Outlet N-E: 4,500 A pulse for 8/20 μs
165 joules pulse form for 10/1,000 μs (outlet)
< 1 ns
HO5VV-F 3G 1.5 mm²
