GB
Fan Heaters
devitemp fan heaters are suitable for portable use
or can be installed permanently at a height of at
least 1.8 metres. The heaters are splash proof
and can be used in dry and humid rooms.
NB: See fig. C for disassembly of the
housing.
Permanent Installation (fixed)
The heater can be installed horizontally or at a
downward gradient of 15º.
1. The fixings are attached to the housing
by use of 4 screws. The two spacing
washers are placed between the hou-
sing and tubular fram (in the bottom
hole).
2. Mark the hole positions. Drill out 4 holes
to attach the fixing to the wall. Use M8
screws.
3. Now fix the heater in the top screws and
attach the bottom screws.
Use of devitemp
List of signs
Off
Fan on
Half fan and half heat
Full fan and half heat
Full fan and full heat
devitemp fan heaters require no maintenance.
However, it is recommended to clean the fan
heater of dust by means of compressed air after
long time of use or after use in dusty rooms.
Electrical Installation
Installation must be carried out with a multipoled
contact breaker with a contact space measuring
at least 3 mm per pole. Permanent installation
must always be performed by an authorised
electrician in accordance with current regulations.
Only the electrician has knowledge of current
installations.
The terminals are accessible if the screws and
the plate on the right side are removed.
Overheating Protection
The fan heaters have a safety cutout which
disconnects the supply if the motor fails or if over-
heating occurs. After cooling down the fan heater,
reset can be done with a screwdriver through
the hole in the instrument panel. If the fan heater
does not start after re-connection you should
contact an electrician.
Warning
Parts of the fan housing become hot during use.
The fan heater must not be installed beneath
electrical switches and sockets.
This appliance is not intended for use by per-
sons (including children) with reduced physical,
sensory or mental capabilities, or lack of expe-
rience and knowledge, unless they have been
given supervision or instruction concerning use
of the appliance by a person responsible for their
safety.
Children should be supervised to ensure that they
do not play with the appliance.
Do not use the fan heater near bath tubs, cabi-
net showers, wash basins or swimming pools.
Concerning use of fixed fan heaters which may
be used in bathrooms the fan heater must be
installed thus power switch and other controls
cannot be reached from the bath tub or cabinet
shower. The fan heaters must not be placed near
ble objects. The distances are min.
imflamma
distances. The fan heater must not be cove-
red during use because of fire risk.
Timer
To set time delay rotate the knob clockwise
and then turn back anticlockwise to required
setting.
