Product Information - Read product information carefully before fitting and follow for correct use
IN8434
ULTI Loader - Product and Maintenance Information
E.01. The fitter, end user and anyone using the
product must receive and read both this document
and the supplied fitting instructions. Retain both the
fitting instructions and this document for future use.
EN
DA
03
09
FR
SV
04
10
DE
05
NL
06
IT
07
ES
08
This PRODUCT INFORMATION is the property of VAN GUARD ACCESSORIES LTD. and must not be used for
manufacturing purposes, copied nor communicated in any way to third parties without written
permission from VAN GUARD ACCESSORIES LTD.
IN8434_A
(CN:NR)
MAX
60KG
C.01. The ULTI Loader has a maximum load limit of
60kg. This limit however is always subordinate to
the maximum roof load carrying capacity as advised
by the vehicle manufacturer.
B.07. Prior to any travel, verify that both lever
latches are fully engaged.
MAX
???KG
MAX
???KG
C.02. Refer to the vehicle manufacturers handbook
to establish the maximum roof load carrying
capacity for your vehicle. Do not exceed this limit.
B.08. Prior to any travel, inspect the securing straps
and replace them if any signs of deterioration or
damage are evident.
????mm
????mm
C.10. For optimum operation, the ULTI Loader must
be adjusted to suit vehicle height and ladder length.
Refer to manual IN8430 (single ladders) or IN8431
(double ladders).
2
1
C.05. Always secure each ladder with two straps.
Using only one strap is not sufficient and is
prohibited.
Van Guard Accessories Ltd
Fair Oak Close, Exeter Airport Business Park,
Exeter, Devon, EX5 2UL
www.van-guard.co.uk
IN8434 - 01 OF 10
