8.2 Teileliste
Nr. Bezeichnung (ENG)
No Spec
1 Main Frame
2 Front Bottom Tube
3 Rear Bottom Tube
4 Screw M8*55
5 Spring washer D8
6 Washer D8*Φ16*15*1.5
7 Feet Cap
8 Adjust Feet Cap
9L/R Pedal Weld
10L/R Pedal
11 Bolt M8*50
12 Nylon Nut M8
13 Axis Cap
14 Slider Board
15 Screw M6*45
16 Nylon M6
17 Round Tube Cap
18 Screw
19 Axis 6200Z
20 Slider Wheel
21 Bolt M8*12*Φ10*32
22 Sub Wheel
23 Nylon M10
24 Square Cap
25 Connect metal
26 Bolt M8*9*Φ10*12
27 Sleeve
28 Bolt M8*12*Φ10*12*Φ8*31
29L/R L&R Swing Rod
30 D Washer
31 Washer D8*Φ28*2
32 Spring Washer D8
30
STEPPER PLUS
Anz.
Qty
1
1
1
8
8
12
2
2
2
2
4
7
10
2
4
9
4
2
4
2
2
2
2
2
2
2
8
2
2
2
2
2
