Setting Up Stimulus Telephones Integral E3 digital at CS I55
Setting Up Stimulus Telephones Integral E3 digital at CS I55
Installation Instructions
11/02
When inserting the connecting cable, the telephone-model can
be choosen. Then the keys m1 – m4 have different functions.
When inserting the connecting cable, one of the keys 1, 2, ... 9,
*, # have to be pressed. Default state is E3 (prepared for
I55 ≥ E07 and I5 ≥ R2).
pressed key
1, 2, 3, or 4
5, 6, 7, or 8
9, *, 0, or #
Notice: E3 digital at I55 SW ≤ E06.2 is currently
recommended exclusively in the mode as TB13.
The recommendation as E3 will happen with I55
SW E07.
state
E3
TE13.14
TB13.14
