Mounting Instructions

The B127M-004-H, B127M-100-H and B127M-101-H include

mounting hardware that allows for a variety of mounting

methods.

The following images illustrate how the included mounting

brackets can be attached for different installations.

Note: The model shown in the below images is for illustrative purposes

only. Your product may vary by model number, size or port orientation.

The mounting options for all over Cat6 units are the same.

Wall-Mount

19" Rack-Mount

Pole-Mount
