Start-up

Guide. All current technical documents and updates are
provided at www.eQ-3.de.
5 Start-up
5.1

Installation and teaching-in

Please read this entire section before starting
the teach-in procedure.
First set up your Homematic IP Access Point via
the Homematic IP app to enable operation of
other Homematic IP devices within your system.
For further information, please refer to the oper-
ating manual of the Access Point.
To integrate the pluggable switch into your system and
enable it to communicate with other Homematic IP de-
vices, you must teach-in the device to your Homematic
IP Access Point first.
To teach-in the pluggable switch, please proceed as fol-
lows:
• Open the Homematic IP app on your smart-
phone.
• Select the menu item "Teach-in device".
• Plug in the switch into the desired socket (see
figure 2).
• Teach-in mode remains activated for 3 minutes.
30
You can manually start the teach-in mode for an-
other 3 minutes by pressing the system button (A)
shortly (see figure 3).
• Your device will automatically appear in the Home-
matic IP app.
• To confirm, please enter the last four digits of the
device number (SGTIN) in your app or scan the QR
code. Therefore, please see the sticker supplied or at-
tached to the device.
• Please wait until teach-in is completed.
• If teaching-in was successful, the LED lights up green.
• If the LED lights up red, please try again.
• Select the desired solution for your device.
• In the app, give the device a name and allocate it to
a room.
After teaching-in, loads such as electric heaters can be eas-
ily connected to the pluggable switch. Connected loads can
then be switched on and off.
6

Operation

After teaching-in and installing have been performed, simple
operations are available directly on the device.
Press the system button (A) shortly to switch on and
•
off connected loads.
Operation
31
