CA 10.8
Displays of LED
red green
off flashes Battery is charging.
Charging process finished.
off on
Maintenance charging.
See "Charging process".
Battery is too hot or too
flashes off
cold.
on off Battery or charger is faulty.
See "Fault messages".
Charging process
CAUTION!
Use only original batteries in the supplied
battery charger.
NOTE
Battery and charger heat up during the
charging process. This is perfectly normal!
 Insert the charger mains plug.
The LED fault message and the LED
charge status light up for a short time.
 Insert battery into the charger as far as
stop.
The LED charge status flashes and the
battery is charged.
When the battery is fully charged, the
LED charge status is lit continuously.
 Remove the battery from the charger.
 Pull out the mains plug.
Fault messages
If the LED fault message lights up after the
battery is inserted into the charger, there is
an fault with the battery or charger.
The LED warning message is lit up
continuously:
– The battery is too hot or too cold.
The charging process starts when the
battery reaches the charging tempera-
ture (0°C...40°C).
The LED fault message flashes or none
of the two LEDs lights up:
– Remove battery from the charger.
Check contacts at charger and battery
for contamination and clean if necessary.
Reinsert battery. The battery is faulty
if the same display appears again.
Replace battery or have it checked in
a professional workshop.
– If this fault message is also displayed
with a different battery, then there is
a fault with the charger. Have the charger
checked by a professional workshop.

Maintenance and care

WARNING!
Before performing any work, pull out the
mains plug. Do not use water or liquid
detergents.
 Remove dirt and dust from the housing
with a paint brush or dry cloth.
9
