F it t in g In s t r u c t io n s
AC Schnitzer Front Splitter - i3 (I01) -
Fitting...
Fig. 35
From behind, insert underfloor cladding between
standard front skirt and AC Schnitzer front splitter and
tighten using the black fixing bolts 5x35mm supplied.
Where applicable:
Fig. 36
Affix the AC Schnitzer sticker supplied in the recess
provided in the AC Schnitzer front splitter.
Subject to errors, modifications and technical development !
AC Schnitzer - automobile Technik - Neuenhofstraße 160 - D - 52078 Aachen - Tel. 0241/5688 -130
Fitting Instructions No.: 5111 501 110 / Issue: 27.05.2019 / TSch
