ICfly Motorbox 912
Installation Guide & User Manual
EGT2 EGT1
EGT1 & EGT2
Positiver Kontakt
Negativer Kontakt
Pi
Funktion
1-1
A0
1-2
A1
1-3
A2
1-4
A3
1-5
A4
1-6
A5
1-7
A6
1-8
A7
1-9
A8
1-10
A9
1-11
GND
1-12
+12V
In-Circuit GmbH
Boltenhagener Str. 124
D-011109 Dresden
CAN-4
CAN-1
Funktion
Nickel Chrom
Nickellegierung
Beschreibung
oil pressure
fuel pressure
oiltemp
CHT1
CHT2
OAT
Außentemp. KTY-210
Fuel L
Fuel R
AirBoxTemp
FLAPS
Masse
+ 12V DC input
Document-Nr: 30510001101A
1-1
2-1
Pin
CAN-1
CAN-2
CAN-3
CAN-4
Pin
Funktion
Beschreibung
2-1
MAP
MAP_IN
2-2
GND
Masse
2-3
+5V
+ 5V DC output
2-4
+12V
+ 12V DC output
2-5
GND
Masse
2-6
Amps
AMPS_IN
2-7
+12V
+ 12V DC output
2-8
FuelF
FUEL-F_IN
2-9
GND
Masse
2-10
RPM
Counter Inputs for
Engine Speed
2-11
GND
Masse
2-12
+12V
+ 12V DC input
1-12
2-12
Funktion
GND
CAN_L
CAN_H
12V output
