4. COMMISSIONING

The installation must be performed by a qualified professional.
Please check the battery for charge and integrity before each start-up. Furthermore, it is NOT recommended
to make any changes to the charging cable, charger, pump or battery by yourself. It is not certain whether
this modification is technically correct, so this warranty is void. It must be ensured that the pump is
sufficiently cooled down during prolonged operation.
Universal pumps are electrical products, which have to be protected against outer influences, f.e. caused by weather.
Only use the pump in well-ventilated rooms and areas with enough fresh air. The floor, on which the pump may be
used, should be flat. Please keep enough space from walls. Place the tank as near to the pump as possible.
The specified suction lift is the maximum suction at optimal conditions. The suction line to the pump has to be steadily increa-
sing. The pump and the suction pipe must be filled with the used medium before turning „on" the pump. Do not reduce
the cross area of suction and discharge lines. Connect suction and discharge lines to the pump by means of reinforced metal
hose. Connect the check valve with filter basket (not included in the standard scope of delivery of the pump) tightly to the end
of the suction line. For stationary use please place the pump on rubber pads to reduce vibration transmission to and from the
pump and thereby prevent damage caused. The suction and discharge line should be connected to to the pump in souch way,
that no mechanical stress on the connections occure. For example, Fix lines by pipe clamps with rubber insert on the wall.
CAUTION: Do not connect a hose more than 5m 1 inch on the pressure side. For smaller hose diameters, use
corresponding short hoses. When using a pump nozzle, it is absolutely necessary to ensure that the pump is switched
off immediately after the nozzle is closed. These measures must be adhered to in order to avoid damage of pumps.

5. INSTALLATION

l Connect all parts as shown in point 13.
(Note: The suction line must be filled with the medium used before switching on the pump).
l Fully charge the battery before use. Connect the battery to the device and start the pump with the on/off switch.
l Refuel as usual.
l When fueling is complete, return the nozzle to its storage position and turn
off the pump immediately.
Schematic drawings can be found on page 13
Please install the pump on solid walls or grounds.
DO NOT attach the pump to cavity or gypsum walls, as
these can amplify vibration, damaging the pump and
significantly increasing the pump's operating noise.
Always use vibration dampers for installation to avoid
damage to the pump.
6. SECURITY TIPS
l Obey absolutely valid regulations on the electrical security
l It is recommended not to let the pump operate for more than 30-40 min. at a time (risk of overheating)
l Never run pump dry. The idle time should not exceed 30 seconds
l Never run pump against pressure
l Never pump liquid food products
l Before usage, check on the tightness of the hose clamps
l Pay attention to the max. liquid temperature of 35°C
l Switch off pump immediately after usage. The pump must not operate against closed tap valve for more than 1-2 minutes
l Don't move the pump in any way, while it's running. It is recommended to work for 30-40 minutes at a time
l During longer unused times, clean the pump, wash it out with clean medium used, dry and store it at room
temperature. If the pump was used with water, it is recommended to blow it through with a compressor before storage.
l ALWAYS supervise and watch the pump, while using
l Operation can not be performed by children and young people under 16 and people with intellectual disabilities
l The pump must be protected from rain and moisture. The pump may only be operated in dry rooms.
The ingress of water into the energized components of the pump increases the risk of electric shock or short
circuit of the battery.
1
 
 
English 3
Vibrationsdämpfer /
Vibration damper
1
