7. To tighten the camera and back plate firmly, screw the nut via the back plate to the tube of the
camera.
8. Connect the connector of the flat cable to the connector on the back plate as shown in the image.
9. At the back side of the monitor is the monitor connector. This connector fits into the connector on
the back plate. (See previous image).
Place the monitor on the back plate and make sure the monitor is pushed correctly on the back
plate.
Adhesive tape
Flat cable connector
Back plate
Nut
Monitor connector
4
Screw + plastic cover
Battery compartment
