SPARE PARTS LIST

No Designation
1 Computer
2 Phillips screw M4*12
3 Medium cable
4 Handlebar
5 End cap Φ25*16
6 Foam Φ23*3*630
7 Hand pulse sensor
8 Phillips screw ST4.0*19
9 Hand pulse sensor cable
10 StopleΦ12*11*Φ3
11 T-button
12 --
13 Washer d4*Φ12*1
14 Small cover
15 Washer d8*Φ20*R16*2
16 Support tube
17 Control of the tractive force
18 Phillips screw M5*35
19 Washer d5*Φ20*R30*1
20 Screw M8*20*S6
21 Washer d8*Ф20*2
22 Front cross support
23 Screw M8*50*20*S6
24L/R End cap
25 End cap
26 Screw ST4.2*16*Φ8
28 Main frame
29L/R Housing
31 Phillips screw ST4.2*19*Φ8
32 Phillips screw ST4.0*10*Φ6
33 End cap
34 Belt 6PJ410
35 Axis
36 PulleyΦ240
37 Hexagon bolt M6*15
38 Nylon nut M6
39 Spacer bushing Φ17.2*Φ22*4
40 Ball bearing
Piece No
1 41 Shaft d17*Φ23*0.3
4 42 Snap ring D17
1 43 Crank
1 44 Nut M10*1.25*H7
2 45 Small cover
2 46 Sensor L=1000
2 47 MagnetΦ15*7
2 48 Tension rope
1 49 Socket
1 50 Plastic cover seat post
1 51 Vertical seat post
-- 52 Knob M10
4 53 Knob M16
1 54 Washer d10*Φ20*2
2 55 Seatpost
1 56 End cap
1 58 Nylon nut M8
1 59 Saddle
1 Flywheel
4 60 Flange nut M10*1.0*H9*S14
9 61 Nut M10*1.0*H5*S17
1 62 Holder
4 63 Steel shackle
2 64 Screw
2 65 Nylon nut M8*H7.5*S13
8 66 Tension spring Φ2,5*Φ16*75*N17
1 67 Idle wheel Ф37*Ф32*24
2 68 Bearing 6000-RS
7 69 Washer d6*Φ16*1.5
1 70 Hexagon bolt M6*12*S10
2 71 Shipping tube
1 72 End cap
1 73 Screw M8*72*20*S6
1 74 Washer d6*Φ12*1.2
4 76L/R Pedal
4 82 Rear cross support
1 A Allen key S6
2 B Wrench S13-14-15
24
OPERATING INSTRUCTIONS
Designation Piece
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
2
1
1
1
1
1
2
1
1
2
4
4
2
2
1
1
1
