Accessories
The air conditioning system comes with the following accessories. Use all of the installation
parts and accessories to install the air conditioner. Improper installation may result in water
leakage, electrical shock and 昀椀re, or cause the equipment to fail. The items are not included
with the air conditioner must be purchased separately.
Name of Accessories
Manual
Drain joint
(for cooling &
heating models)
Seal
(for cooling &
heating models)
Mounting plate
Anchor
Mounting plate
昀椀xing screw
Name
Connecting pipe assembly
Magnetic ring and belt
(if supplied ,please refer
to the wiring diagram to
install it on the connective
cable.)
Page 16-GB
Q'ty (pc)
Shape
2~3
1
1
1
5~8
(depending
on models)
5~8
(depending
on models)
Shape
Liquid side
Gas side
1 2 3
Pass the belt through the
hole of the Magnetic ring
to 昀椀x it on the cable
Name of
Q'ty (pc)
Accessories
Remote controller
Battery
Remote controller
holder (optional)
Fixing screw for
remote controller
holder (optional)
Small Filter
(Need to be installed
on the back of main air
(depending
昀椀lter by the authorized
on models)
technician while
installing the machine)
ø6.35 (1/4 in)
ø9.52 (3/8in)
Parts you must purchase
ø9.52 (3/8in)
separately. Consult the dealer
about the proper pipe size of
ø12.7 (1/2in)
the unit you purchased.
ø16 (5/8in)
ø19 (3/4in)
Varies by model
Shape
1
2
1
2
1~2
Quantity (PC)
