2. Screw bits are marked with their dimensions and
shape. If you are unsure, always try out first whether
the bit sits in the screw head without play.
8.5 Adjusting the direction of rotation
(Fig. 1)
ATTENTION
The direction of rotation switch may only be actuated
when idle.
With the direction of rotation switch, you can select the di-
rection of rotation of the product (clockwise or anti-clock-
wise) and secure the product from being switched on un-
intentionally. The arrow on the direction of rotation switch
indicates the working direction.
1. Wait until the product has come to a standstill.
2. Push the direction of rotation switch (8) to the desired
position:
– Clockwise rotation: For screwing in screws
and nuts. Press the direction of rotation switch on
the right, with the arrow pointing forwards.
– Anti-clockwise rotation: For undoing screws
and nuts. Press the direction of rotation switch on
the left, with the arrow pointing backwards.
3. Switch lock: Put the direction of rotation switch in the
centre position.
8.6 On/Off switch (7) (Fig. 1)
1. To switch on the product, push the on/off switch (7).
2. To switch off, release the on/off switch (7).
If you put the direction of rotation switch (8) in the cen-
tre position, the product is secured from being
switched on.
8.6.1 LED work lamp (6) (Fig. 1)
This product is equipped with an LED work lamp to illumi-
nate the immediate work area and improve visibility in
poorly lit environments.
CAUTION
Do not look directly into the LED work lamp or the light
source.
1. The LED work lamp (6) lights up automatically as
soon as the product is switched on.
Note:
The LED work lamp remains lit up for approx. 10 seconds
after the product is switched off.
8.7 Setting the speed/tightening torque
(Fig. 1)
1. Apply light pressure to the on/of switch (7). This en-
sures a low speed/tightening torque. Applying more
pressure to the on/off switch (7) increases the speed/
tightening torque.
Note:
The tightening torque is dependent on the chosen speed
and the impact duration.
18 | GB
ATTENTION
The actual tightening torque achieved must always be
checked with a torque wrench!
Note:
The integrated motor brake ensures a quick standstill.
9 Working instructions
Note:
* = not included in the scope of delivery!
Undoing
• If the screws/nuts are very tight or rusted, they must
be "loosened" with a wheel brace* or torque wrench*
Tightening
ATTENTION
The cordless impact screwdriver should only be used
for undoing screws/nuts. However, if screws/nuts are to
be tightened with the impact screwdriver, a torque limit-
er* designed for this purpose must be used as this may
otherwise damage the screw connection.
• Carefully insert the screw/nut into the thread before
tightening.
• Only tighten the screws/nuts, for which a torque speci-
fication applies (e.g. in the motor vehicle sector, by
the specifications of the vehicle manufacturer), with a
torque limiter designed for this purpose.
Torque
• Small screws*/bits* may be damaged if the torque or
the speed is set too high.
WARNING
Retighten or check the screws/nuts with a torque
wrench* to the torque stipulated by the manufacturer!
10 Cleaning and maintenance
WARNING
Have maintenance and repair tasks that are
not described in this operating manual, car-
ried out by a specialist workshop. Use only
original spare parts.
There is a risk of accident! Always perform
maintenance and cleaning work with the bat-
tery removed. There is a danger of injury! Let
the Product cool down before all mainte-
nance and cleaning tasks. Elements of the
engine are hot. There is a danger of injury
and burning!
The product can start unexpectedly and cause injuries.
– Remove the battery.
– Allow the product to cool down.
– Remove the tool attachment.
