Unpacking the carton

Figure 1
Bracket carton contents
Other equipment you may need
Figure 2
Tools and other equipment
you may need for installing
the bracket
Español Français Italiano
Carefully unpack the carton and save the packing materials, which provide the safest means
for shipping or transporting. Check to be sure you have all of the supplied parts (Figure 1).
Platform (1)
Sheet metal screws (3)
Screw anchors (3)
Toggle bolts (3)
Cabinet screws (3)
Capnuts (3)
This guide provides information on the proper use of several types of mounting hardware
(shown above) for each of the four bracket-mounting options explained later in the guide.
Use only the mounting hardware that is supplied.
You need to use the proper tools to drill holes for the mounting hardware and to assemble
and mount the bracket properly to the surface you have chosen. Consider using the tools
shown here (Figure 2).
Drill bit for your
mounting surface
Spade bit
for wallboard
Masonry bit
Electric drill
for masonry
Twist bit
for wood
Nederlands Thai
B
RACKET INSTALLATION
Footpads (2)
Bracing pin (1)
End cap (1)
Toggle wings (3)
Eye protection
for drilling
Pencil
Korean S. Chin Arabic
Mounting assembly (1)
Assembly
screws (2)
Plastic straps (3)
Mounting pads (3)
Stud finder
Phillips head
screwdriver
Carpenter's level
3
