3.2 Technical data
Type designation
Maximum belt width
Belt thickness
Z-splices
Maximum heating temperature
Total weight
Dimensions (L x W x H)
Connection requirements (alternative)
1 Phase (Item no. 870103)
1 Phase (Item no. 870109)
3.3 Operating principle
The Siegling Blizzard heating clamp is a compact solution
used to splice (heat and cool) thermoplastic belts (e.g. PVC,
polyurethane). no other accessories are required, such as an
external control unit or cooling clamp.
The Siegling Blizzard heating clamp is electrically heated
and air-cooled using fans. The heating and subsequent
cooling processes run automatically according to the previ-
ously entered values.
7
[mm]
[mm]
[mm] 35:5.75 / 35:11.5 / 70:11.5 / 110:11.5
[°C]
[kg]
[mm]
[V/Hz]
[V/Hz]
Blizzard HC 120/40
40
1.3 – 3.2
210
2.0
310 x 145 x 130
230/50
115/60
Operating modes
Start mode
Heating mode
including holding time
Cooling mode
Fig. 3.3.1
Diagram of operating modes.
after the heating clamp has been switched on, three operating modes
are run through in sequence. From the start mode, a setting mode and
calibration mode for the heating and cooling parameters can be started if
necessary.
Setting mode
Calibration mode
