BOERPLAY Amazonite Installationsanleitung Seite 99

3
/ 7
Detail C (9x)
KST.DOP.006.030
© Copyright BOERplay 21-9-2023
B (9x)
BSR.002.005.030
KST.KNP.010.090
KST.DON.010.060
BSR.030.010.002
BSR.010.010.010
KST.DOP.010.060
Revision:
55 mm
BSR.024.010.055
MOD BBP 782 G22
x
9 BSR.002.005.030
x
9 BSR.010.010.010
x
9 BSR.024.010.055
x
9 BSR.030.010.002
x
9 KST.DON.010.060
x
9 KST.DOP.006.030
x
9 KST.DOP.010.060
x
9 KST.KNP.010.090
