BOERPLAY Amazonite Installationsanleitung Seite 78

3
/ 3
Detail B (6x)
KST.DON.010.060
BSR.030.010.002
BSR.021.010.130
KST.DOP.010.060
© Copyright BOERplay 21-9-2023 Revision:
B (6x)
! Max 12 Nm !
KST.DOP.010.060
BSR.010.010.010
BSR.030.010.002
KST.DON.010.060
MOD BBP 775 G22
Nm
x
6 BSR.010.010.010
x
6 BSR.021.010.130
x
12 BSR.030.010.002
x
12 KST.DON.010.060
x
12 KST.DOP.010.060
