ATTENTION
Please read the following instructions carefully to ensure that mounting operation will be carried out correctly. These instructions
should be properly preserved for future reference.
CAUTION
1. The product must be installed by qualified technicians. The power supply must be cut before installation.
2. The installation wiring must be 2 x 1.0 mm² at least and wired in accordance with the latest IEE electrical regulations
or the national requirements.
3. Do not touch the LEDs while installing or maintaining.
4. This product contains a light source of energy efficiency class D.

TECHNICAL DATA

Supply voltage: AC 220-240V 50/60Hz
Light source: SMD2835 LED
Operating temperature: -20°C - +50°C (Sensor version: upto max. +40°C)
Electrical safety class: Class II

TECHNICAL INFORMATION

Standard version
Input
Art. no. Color
power
40010300 White 6W
40010310 Black 6W
40010301 White 7W
40010311 Black 7W
MICROWAVE SENSOR - DESCRIPTION
Detection sensitivity: 10%, 25%, 50% or 100% (adjustable)
Daylight on: 5 - 50Lux, adjustable or disabled
Daylight off: 25 - 150Lux, adjustable or disabled
Hold time: 5sec; 1 - 5 - 10min (adjustable)
Hold time orientation lighting:
Off - 10min - 30min - ∞ (adjustable)
Stand-by dim level: 10% or 25% (adjustable)
Mounting height: 6m max.
Motion detection: 0.3 ~ 3m/s
Lumen
Sensor
switchable
700Lm / 350Lm -
700Lm / 350Lm -
700Lm / 350Lm Yes
700Lm / 350Lm Yes
Wall mounting detection area (Unit: m)
Suggested installation height: 2m
www.prolumia.com
280
Semi shielded version
Input
Art. no. Color
power
40010320 White 6W
40010330 Black 6W
40010321 White 7W
40010331 Black 7W
Ceiling mounting detection area (Unit: m)
280
Lumen
Sensor
switchable
500Lm / 250Lm -
500Lm / 250Lm -
500Lm / 250Lm Yes
500Lm / 250Lm Yes
Suggested installation height: 3m
