GENERAL FUNCTIONS AND CONTROLS
8. IN BUTTON－This function allows you to set
a cue point without music interrupt. This
button also sets the starting point of a
seamless loop.
9. OUT BUTTON－This button is used to set the
ending point of a loop. A loop is started by
pressing the IN button; pressing the OUT
button set the loop ending point. The loop will
continue to play until the OUT button is
pressed once again.
10. RELOOP BUTTON－If a seamless loop has
been made, but the CD player is not actively
in seamless loop mode (a loop is not playing),
pressing the RELOOP button will instantly
reactivate the seamless loop mode. To exit
loop, press the OUT button. LOOP and
RELOOP will appear in the LCD display when
the reloop function is available. During play
mode, pressing the RELOOP button will
instantly return play the last set point without
interrupt of music.
11. JOG WHEEL－This wheel has three functions:
(1) The jog wheel will act as a frame search
control when the CD in the pause or cue
mode, allowing you to set a point.
(2) The wheel also works as a pitch bend
during playback. Turning the wheel
clockwise will increase the pitch percentage
up to 100%, and turning the wheel counter-
clockwise will decrease the pitch percentage
down to –100%. The pitch bend will be
determined on how long you turn the jog
wheel continuously.
(3) The jog wheel can be used with the help
of the TIME and RATIO knob to set
effects and samples parameter adjustment.
12. JOG SEARCH KNOB－Press this knob to
toggle the function of the jog wheel and LED
is lit.The search function has 4 forward and 4
reverse speed allowing you to quickly scan
through tracks. The more you turn the wheel
in either direction the faster you search.
13. SAMPLER BUTTON
Press this button, then press the desired
BANK button to set the sampler mode.
When sampler mode is set, then sampler
will mix the CD music together. The sampler
can play even no disc inside. The sampler
will play only once or continuous depends
on SINGLE is indicated or not on the LCD.
And press the SAMPLER button again to
cancel sampler function.
When in the playback of sampler loop
mode, the TIME PARAMETER is to adjust
pitch and the RATIO PARAMETER is to
adjust volume.
Press and hold the SAMPLER button until
LED blinks will enable the Sample scratch;
press the button again to cancle function.
14. CUE BUTTON －Pressing the CUE button
during playback immediately pauses playback
and returns the track to the last set cue point.
In pause mode and the CD is at the cue point,
press the CUE button to provide cue monitor.
The CUE LED will glow when the CD is at the
cue point.
15. PLAY/PAUSE BUTTON－Each press of the
button to change from play to pause or from
pause to play. In skid mode, press this button
to break or slow start.
16. MEMORY BUTTON－Press this button to set
the memory mode, then press the desired
BANK button to memorized the music from
the cue point. The music length to be
memorized is determined by the length of
BANK. When the memory mode is set, the
MEMORY LED is lit. You can also memorize
the BANKs by pressing the memory for 1 sec.
To recall the BANKs, just make the memory
mode set before put the disc slot in.
17. CD SLOT－Gently slide a CD with the picture
facing upwards into the slot. The CD is
automatically pulled in.
18. 4 HOT CUE BUTTONS－Press the desired
BANK button when the MEMORY LED is lit
will set the memory mode. The music from
the cue point will be memorized to the flash
bank. Press the desired BANK button when
the SAMPLER LED is lit will set the sampler
mode. The sampler length is determined by
the smaller one of out point and bank length.
Press the desired BANK button will return to
the start point instantly. The LED of the BANK
button actived will be flashing.
19. TAP BUTTON
The TAP button is used for manual BPM.
Press and hold the TAP button then turn
the TIME or RATIO knob will enable you to
adjust BPM value.
Hold down the TAP button to switch to Auto
BPM.
20. BPM BUTTON－To change the BPM/ PITCH
display by pressing the BPM button.
21. REVERSE BUTTON－This button activates
reverse play mode. This function will play
your track or sampler in reverse.
22. PITCH RANGE BUTTON－Press the button
in order to change pitch percentage of 6%,
12%, 25%, 100%.
23. PITCH BEND BUTTONS－The desired pitch
of CD decrease or increase when button is
pressing and returns to the original pitch
when the button is released.
24. RATIO BUTTON (Parameter)－Turn the RATIO
knob or hold the RATIO knob and turn the jog
wheel to adjust the parameter ratio value.
4
TOP PANEL
