LaserJet Pro M101-M104,
LaserJet Ultra M105-M106
Getting Started Guide
IMPORTANT:
Steps 1 - 3
First, follow
on the printer hardware
setup poster, then continue
with
Step
4.
5. Select a connection method
USB connection directly between the
printer and the computer
Use an A-to-B type USB cable.
Windows
1.
Do not connect the USB cable before installing the software. The
installation process prompts to connect the cable at the appropriate
time. If the cable is already connected, restart the printer when
installation prompts to connect the cable.
2.
Continue to
"6. Download and install the software."
OS X
1.
Connect the USB cable between the computer and the printer before
installing the software.
2. Continue to
"6. Download and install the software."
Wired (Ethernet) network connection
(optional)
Use a standard network cable.
1.
Connect the network cable to the printer and to the network. Wait a few
minutes for the printer to acquire a network address.
2.
Continue to
"6. Download and install the software."
www.hp.com/support/ljM101
4. Set up the control panel
At the printer control panel, check the LED status before beginning software installation.
www.register.hp.com
Perform a wireless installation
(wireless models only)
Before starting the installation, verify that the wireless access point is working
correctly. Make sure that the printer, router, and computer are all turned on
and that the computer is connected to the same wireless network that the
printer will be connected to.
1. Place the CD in the CD-ROM drive, navigate to setup.exe and double click.
When the Printer connections dialog appears, choose Make a wireless
connection to the device.
2. Follow the on-screen instructions.
3. Select the printer detected by the software. If the printer cannot be
detected by the installer, manually input the printer's IP address to
continue the installation.
NOTE:
Print a configuration page to find the printer's IP address. At the
printer control panel, press and hold the Resume/Cancel button for
5 seconds, and then release the Resume/Cancel button to print the
configuration page. The IP address is listed on the configuration page
in the Network Information section.
Manually configure the IP address
See the printer user guide for information on how to manually configure the IP
address www.hp.com/support/ljM101.
1
English................. 1
Français ............... 3
Deutsch ............... 5
Italiano ................ 8
Español ............. 10
Català ................ 12
Dansk ................ 14
Nederlands ........ 16
Eesti................... 18
Suomi ................ 20
Latviešu ............. 22
Lietuvių ............. 24
Norsk ................. 26
Português ......... 28
Svenska ............. 30
