INSTRUCTION MANUAL
10. Connect the duct securely to the reflector flanges.
11. Plug the cordset into the ballast.
Dual BulB inStallation
1. Out of the box, the Raptor 8 Dual arrives ready to operate with two 1,000 watt lamps.
Adjust the cordset collar if necessary for ideal lamp placement in the reflector.
2. Screw in the light bulbs. Adjust the lamp position if necessary.
3. Wipe residue off the bulbs and the reflector with a clean, soft cloth.
4. Secure the glass lens back into the chassis and reattach to the ceiling.
5. Route cordsets through white rubber square grommets to seal the cord in the flange
cord opening slot.
6. Connect the duct securely to the reflector flanges.
7. Plug the cordsets into the ballasts.
CHanging tHe BulBS
1. Turn off the ballast(s) and allow the unit to cool.

Operation

2. Twist the bulb counter-clockwise to remove it from the reflector. HID lamps contain
mercury; please recycle the bulbs responsibly. For more information, visit lamprecycle.org.
3. Install the replacement lamp. Wipe any residue off the glass with a soft, clean cloth.
Cleaning tHe RefleCtoR
1. Turn off the reflector and allow it to cool.
2. Lift the reflector off its hanging mechanism. Set the reflector bulb-side up on a sturdy
surface. Optional: Place the reflector on a towel or soft cloth.
3. Unscrew the bulb. Set aside.
4. Mix warm, mild soap and water and apply sparingly with a clean washcloth.
Dry with a second washcloth. Flip reflector over to cleanse both sides.
5. Run a dry, soft washcloth over bulb to remove dust particles.
6. Screw the bulb back into the reflector
7. Reattach the reflector to its hanging mechanism.
ENG
3
