AXIS F44 Dual Audio Input
Power connector
2-pin terminal block for DC power input. Use a
Safety Extra Low Voltage (SELV) compliant limited
power source (LPS) with either a rated output power
limited to ≤100 W or a rated output current limited
to ≤5 A.
RS232 Connector
5-pin terminal block for the RS232 serial interface used to control auxiliary
equipment. In order to use the RS232 port, a third party application for
AXIS Camera Application Platform is required.
RJ12 Connector
The RJ12 connector is used for connecting the sensor unit to the main
unit. For information on how to shorten the sensor unit cable see Shorten
Sensor Unit Cable on page 8.
The Axis product is intended for indoor use.
Classification
IEC/EN 60529
Temperature
-30 °C to 60 °C
(-22 °F to 140 °F)
20
Humidity
10-85% RH (non-
condensing)
